By order of shipyards, maritime component suppliers and engineering offices we create detail design engineering including the part dimensioning, 3D modeling and complete fabrication documents.

3D Modeling Workshop Drawing Construction

A selection of engineering tasks we have worked on:

Year Vessel Description Customer
2014 SAR Tenderboat 8,0 m Complete engineering and fabrication documents Shipyard
2014 Survey Launches 8,0 m Complete engineering and fabrication documents Shipyard
2014 Supply Vessel Detail design engineering of aluminium tender boat cradle Shipyard
2014 Diver Boat 8,0 m Complete engineering and fabrication documents Shipyard
2013 Live Stock Carrier 3D Engineering main frame and pens for conversion Engineering office
2013 Cable Laying Barge 3D Engineering of cable laying and deck equipment Engineering office
2012 Cable Laying Vessel 3D Engineering of cable laying and deck equipment Engineering office
2012 Rescue Boat 7,5m Complete engineering and fabrication documents Shipyard
2011 Sail Training Barque Rig Complete rig design, detail engineering, fabrication documents Shipyard
2011 Sail Training Barque Naval architecture, engineering deck equipment & outfitting Shipyard
2011 Cable Laying Barge 3D Engineering of pipe fender racks Engineering office
2010 Rescue Boat 6.5m Complete engineering and fabrication documents Shipyard
2009 Rescue Boat 4.0m Complete engineering and fabrication documents Shipyard
2009 Multi Purpose Cargo 3D Engineering of pipe connections for signalmast Engineering office
2009 Cable Laying Barge 3D Engineering of anchor arrangement and racks Engineering office
2009 Work Boat 10m Complete engineering and fabrication documents Shipyard
2009 Rescue Boat 6.5m Complete engineering and fabrication documents Shipyard
2009 Cargo Boat 14m Complete engineering and fabrication documents Shipyard
2008 Work Boat 6.5m Complete engineering and fabrication documents Shipyard
2007 Heavy Lift Cargo Ship Detail design engineering of crane boom rest Engineering office
2007 Work Boat 3.5m Series Complete engineering and fabrication documents Shipyard
2007 Heavy Lift Cargo Ship 3D Engineering of anchor pocket Engineering office
2007 Mega Yacht Detail design engineering of aluminium equipment components Shipyard
2007 Mega Yacht Detail design engineering of tender boat cradles Shipyard
2006 Crew Boat 10m Series Complete engineering and fabrication documents Shipyard
2005 Rescue Boat 4.5m Series Complete engineering and fabrication documents Shipyard
2005 Work Boat Complete engineering and fabrication documents Shipyard
2004 Work Boat 7m Series Complete engineering and fabrication documents Shipyard
2003 Multi Purpose Cargo Shell expansion including dimensioning Engineering office
2002 Mega Yacht Detail design engineering of equipment foundations Engineering office
2001 Container Vessel Engineering for several double bottom modules Engineering office
2001 Cruise Liner 3D Engineering of equipment rack Engineering office
2001 Mega Yacht Engineering for two helicopter hangar doors Component supplier
2001 Container Vessel 3D piping coordination for fore ship module Engineering office
2001 Cargo Pontoon Shell expansion including dimensioning Engineering office
